TekSpan® Zynox 45 Thread Connector
- Product Code: 60159
TekSpan® Thread Connector
Frame to threaded rod connector, for direct fixing of rods and suspension of threaded
fasteners.
- Pack Qty: 50
Downloads
Description
Direct connector for threaded rod – provides a female thread in M10 that connects directly to TekSpan frame.
Downloads
Technical Data
| Pack-qty | 50 |
|---|---|
| Weight | 0.0360kg/pc |
| Material | Steel |
| Finish | Zinc-Nickel |
| Profile Type | 45mm |
| Thread | M10 |
| Wrench-size | 16 |
| Height-collar-nut | 15mm |
| Tightening-torque | 25Nm |
| Load Fz | 4.5kN |
